Raption
MODELS SPECIFICATIONS
Raption 100 - 480V Models
MODELS CCS1 CCS1 CHA CCS1 T1C32
Maximum AC input
current
132 A 132 A
132 A (@480V 3F)
35 A (@208-240V F-N)
Required power supply
capacity
110 kVA 110 kVA 132 kVA
Maximum output
power
DC: 100 kW (@400Vdc) DC: 100 kW (@400Vdc)
DC: 100 kW(@400Vdc)
AC: 7.4 kW
Output voltage range DC: 150 - 920 Vdc DC: 150 - 920 Vdc
DC: 150 - 920 Vdc
AC: 208 - 240 V~
Maximum output
current
DC: 250 A
DC: 250 A (CCS)
200 A (CHA)
DC: 250 A (CCS)
AC: 32 A
Number of connectors 1 2 2
Connector type
M
B
MODELS CCS1 T2S32 CCS1-CHA T1C32 CCS1-CHA T2S32
Maximum AC input
current
132 A (@480V 3F)
35 A (@208-240V F-N)
132 A (@480V 3F)
35 A (@208-240V F-N)
132 A (@480V 3F)
35 A (@208-240V F-N)
Required power supply
capacity
132 kVA 132 kVA 132 kVA
Maximum output
power
DC: 100 kW(@400Vdc)
AC: 7.4 kW
DC: 100 kW(@400Vdc)
AC: 7.4 kW
DC: 100 kW(@400Vdc)
AC: 7.4 kW
Output voltage range
DC: 150 - 920 Vdc
AC: 208 - 240 V~
DC: 150 - 920 Vdc
AC: 208 - 240 V~
DC: 150 - 920 Vdc
AC: 208 - 240 V~
Maximum output
current
DC: 250 A (CCS)
AC: 32 A
DC: 250 A (CCS)
200 A (CHA)
AC: 32 A
DC: 250 A (CCS)
200 A (CHA)
AC: 32 A
Number of connectors 2 3 3
Connector type
C
M M
B
C
