Circutor Raption Series Service Manual

Service Manual 35
Raption
• Ready LED (green): Electric car has been detected.
• Charge LED (yellow): Power contactor is closed and the vehicle is being charged.
• Error LED (red): Proximity error or ‘E’ status request.
• CPU LED (red): Device powered ON
• RX/TX (yellow): RS-485 communications working.
To update this component it is necessary an ICD3 device.
Updating process for Mode 3 is described in the manual "How to update Mode 3" available
in the Expert Area.
Operation LEDs
Update
Electrical scheme
