Circutor Raption Series Service Manual

Service Manual 9
Raption
Features
1- Cover 2- Exit AC cable 3- AC light beacon 4- CHAdeMO connector 5- Air inlet
6- Air outlet 7- Decorative front
panel
8- Decorative rear
panel
9- Handle 10- CHAdeMO
holder
11- CCS holder 12- AC holder or
socket 32A
(1)
13- CCS light beacon 14- CHAdeMO light
beacon
15- Antenna
16- Air outlet 17- Exit DC cable 18- Touch screen +
Axial fan
19- Emergency button 20- RFID reader
21- Air inlet 22- Air inlet 23- CCS connector 24- Courtesy light
(1)
Depending of the model, the components can vary.

Circutor Raption Series Specifications

General

Brand	Circutor
Model	Raption Series
Category	Battery Charger
Language	English
