GENERAL DATA
Display HMI 8" colour antivandal touch screen
Light beacon RGB Colour indicator
RFID reader
ISO / IEC 14443-1/2/3
MIFARE Classic
RFID Extension
Legic Advant / Legic Prime
ISO 15693/ISO 18092. Sony FeliCa
Rated diversity factor 0.8
CONNECTIVITY
Ethernet 10/100BaseTX (TCP-IP)
Cellular Modem 4G / GPRS / GSM / WiFi Hotspot
(4)
Interface protocol OCPP 1.5 or OCPP1.6J
ENVIRONMENTAL CONDITIONS
Operating temperature -30ºC ... +45ºC
Storage temperature -40ºC ... +60ºC
Operating humidity 5% ... 95% Non-condensing
Sound level in operation < 55 dB
MECHANICAL DATA
Enclosure rating IP54 / IK10
Enclosure material Stainless steel
Enclosure acces Frontal key locked door
Connector type
AC DC
Cable Type 1 / Cable
Type 2 / Socket Type 2
CHAdeMO
(JEVS G105)
COMBO CCS 2/
CCS 1
(3)
Cable length 3 meters / --- 3 meters 3 meters
Net weight 235 kg
Dimensions (D x W x H) 410
(5)
x 940 x 1800 mm
