Cirrus Design Section 7
SR22T Systems Description
P/N 13772-005 7-63P/N 13772-005 7-63
Figure 7-13
Standard Environmental System
CONTROLLER
TEMPERATURE
SENSOR
RAM AIR
FLOOR AIRFLOW
AIR FLOW VALVE
HOT AIR
VALVE
SR22_FM07_3261
RAM AIR
RAM AIR
FRESH AIR
VALVE
CROSSOVER TUBE
FOOT-WARMER
DIFFUSER
DISTRIBUTION
MANIFOLD
FAN
ASSEMBLY
NOTE: Illustration depicts maximum
cabin cooling airflows and
selector settings with optional
Fan installation.
PANEL AIRFLOW
CONTROL PANEL
WINDSHIELD
DIFFUSER
AIR GASPER
MIXING
CHAMBER
SERVO MOTOR
