Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 9 TL1 Commands
TL1 Commands and Autonomous Messages
Table 9-25 REPT ALM DWDM Syntax Description
Parameter Syntax Description
time hh:mm:ss Time of origination of TL1 message.
almcde The alarm severity code for the TL1 message. Possible values
are:
*C Critical alarm.
** Major alarm.
* Minor alarm.
A No alarm. Occurs only when ntfncde is NA.
atag 0 - 999 An integer between 0 and 999 used as a sequence number in
autonomous messages.
aid
Always 1.
1 Directly affecting the optical signal.
conddescr Detailed text description of the event. The conddescr is 1 to 64
characters of ASCII text. See condtype below.
condtype Condition type identifies the type of alarm (maps to
cerent15216EdfaLogEventID). Possible condtype and
corresponding conddescr (in quotes) are:
LOS “Loss of Signal” (input power) alarm
(cerent15216EdfaAlarmLpin).
GAIN “Gain Out of Range” alarm (cerent15216EdfaAlarmGain).
LPOUT “Loss of Output Power” alarm (cerent15216EdfaAlarmLpout).
date yyyy-mm-dd Date of origination of TL1 message.
ntfncde Notification code (maps to cerent15216EdfaAlarmPriority).
Possible values are:
CR Critical alarm.
MJ Major alarm.
MN Minor alarm.
CL Cleared alarm.
NA No alarm.
ocrdat m-d Date (month-day) of the event occurrence (derived from
cerent15216EdfaDateAndTimeString).
ocrtm h-m-s Time (hour-minute-second) of the event occurrence (derived
from cerent15216EdfaDateAndTimeString).
sid string Source identifier uniquely identifies the source of a TL1
autonomous command.
srveff Effect on service. Possible values are:
SA Service affecting.
NSA Non-service affecting.
