Cisco 15216 EDFA2 User Manual

FINAL DRAFT - CISCO CONFIDENTIAL
9-48
Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 9 TL1 Commands
TL1 Commands and Autonomous Messages
9.7.33 RTRV-DWDM
Command RTRV-DWDM
Retrieves the ONS 15216 EDFA2 optical control configuration.
Syntax
RTRV-DWDM:[<tid>]:<aid>:<ctag>;
<sid> <date> <time>
M <ctag> COMPLD
"<aid>:INPWRMICROW=<inputpoweruw>,INPWRDBM=<inputpowerdbm>,OUTPWRMILLIW=<outputpowermw>
,OUTPWRDBM=<outputpowerdbm>,PUMP1CTRLMODE=<pump1ctrlmode>,PUMP1CTRLVALUE=<pump1ctrlvalue>,
PUMP2CTRLMODE=<pump2ctrlmode>,PUMP2CTRLVALUE=<pump2ctrlvalue>,OVERALLGAINMEASURED=<gainmea
sured>,CONFIGGAIN=<gain>,PREATTMEASURED=<preattmeasured>"
;
Example 9-35 RTRV-DWDM Command and Response
Amp01:ONS15216 EDFA2> RTRV-DWDM:Amp01:ALL:123;
Amp01 2002-06-20 14:30:00
M 124 COMPLD
"1:INPWRMICROW=264,INPWRDBM=-1578,OUTPWRMILLIW=172,OUTPWRDBM=237,PUMP1CTRLMODE=GAINTEMP
,PUMP1CTRLVALUE=169,PUMP2CTRLMODE=GAINTEMP,PUMP2CTRLVALUE=169,OVERALLGAINMEASURED=169,CONF
IGGAIN=170,PREATTMEASURED=60"
;
Table 9-39 RTRV-DFLT-SECU Syntax Description
Parameter Syntax Description
date yyyy-mm-dd Date of origination of TL1 message.
time hh:mm:ss Time of origination of TL1 message.
aid EQPT and ALL have same input effect.
EQPT General parameters of the ONS 15216 EDFA2 (not directly
affecting optical signal or power bus).
ALL Any or all of the preceding (command input only).
al Access level of the user. See “Summary of Security Permissions
for TL1 Commands” section on page 9-6 for access level
permissions.
R Read only privileges.
RW Read and write privileges.
RWA Read, write, and administrative privileges.
timeout integer Timeout in minutes.
