Cisco 15216 EDFA2 User Manual

FINAL DRAFT - CISCO CONFIDENTIAL
9-50
Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 9 TL1 Commands
TL1 Commands and Autonomous Messages
9.7.34 RTRV-ENV
Command RTRV-ENV
Retrieves the ONS 15216 EDFA2 environmental parameter configuration.
Syntax
RTRV-ENV:[<tid>]:<aid>:<ctag>;
<sid> <date> <time>
M <ctag> COMPLD
"<aid>:PWRBUSMODE=<pwrbusmode>"
;
Example 9-36 RTRV-ENV Command and Response
Amp01:ONS15216 EDFA2> RTRV-ENV:Amp01:ALL:123;
Amp01 2002-06-20 14:30:00
M 123 COMPLD
"PWR-B:PWRBUSMODE=DUPLEX"
;
gain 130 - 220 Value of gain setpoint in units of 10 dB when mode is
GAINTEMP (gets
cerent15216EdfaConstGainOverallGainMeasured). Same as
OVERALLGAIN.
preattmeasured 0 - 110 Gain pre-attenuation value in units of 10 dB (gets
cerent15216EdfaVariableGainPreAttenuationMeasured).
Table 9-40 RTRV-DWDM Syntax Description (continued)
Parameter Syntax Description
Table 9-41 RTRV-ENV Syntax Description
Parameter Syntax Description
date yyyy-mm-dd Date of origination of TL1 message.
time hh:mm:ss Time of origination of TL1 message.
aid PWR-A, PWR-B, and ALL have same input effect.
PWR-A Affecting Power Bus A (or both A and B).
PWR-B Affecting Power Bus B.
ALL Any or all of the preceding (command input only).
pwrbusmode Power bus mode setting (cerent15216EdfaPowerBusMode).
Possible values are:
SIMPLEX Simplex mode. Requires power only to bus A
(cerent15216EdfaPowerBusMode set to simplex).
DUPLEX Duplex mode (manufacturer default). Requires power to both
bus A and bus B (cerent15216EdfaPowerBusMode set to
duplex).
