FINAL DRAFT - CISCO CONFIDENTIAL
5-21
Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 5 SNMP MIB Installation and Configuration
Setting Up Traps
5.4.8 VersionGroup Table
The cerent15216EdfaVersionGroup table allows users to display the currently loaded image and the
image to be loaded after cutover. Table 5-13 describes cerent15216EdfaVersionGroup table variables.
5.5 Setting Up Traps
Traps are asynchronous notifications sent from the ONS 15216 EDFA2 to a predetermined location (IP
address, subnet mask, etc.). A community entry must be created prior to remotely setting up traps using
either Telnet or a terminal server. Table 5-14 on page 5-22 displays the alarm notification types in the
cerent15216Edfa.mib that initiate a trap.
cerent15216EdfaOpSrcFile
Name
DisplayString (0 to
127 characters)
Read-write Source file name for the Load
operation.
cerent15216EdfaOpTftpSrv
Addr
IpAddress Read-write TFTP file server address for the
Load operation.
cerent15216EdfaOpReset cerent15216EdfaActio
n
Read-write When “perform” is written to this
object, a software reset is
performed.
Table 5-12 cerent15216EdfaOpGroup Variable Descriptions (continued)
Variable Syntax
Maximum
Access Description
Table 5-13 cerent15216EdfaVersionGroup Variable Descriptions
Variable Syntax
Maximum
Access Description
cerent15216EdfaCurrentVersion DisplayString (0 to 255
characters)
Read-only The version of the
currently loaded image.
cerent15216EdfaAlternateVersion DisplayString (0 to 255
characters)
Read-only The version of the
image to be loaded after
a cutover is performed.
