Cisco 15216 EDFA2 User Manual

FINAL DRAFT - CISCO CONFIDENTIAL
2-5
Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 2 Technical Specifications
Front Panel
Figure 2-1 ONS 15216 EDFA2 Dimensions
2.5 Front Panel
Figure 2-2 shows the ONS 15216 EDFA2 front panel in detail. The front panel provides an all-front
access (fibers, power, alarm contact, and management interface) that complies with international
standards.
Figure 2-2 ONS 15216 EDFA2 Front Panel
Table 2-5 on page 2-6 describes the ONS 15216 EDFA2 front panel features.
11 in. Dimension
1 3/4 in. Height
17 3/16 in. Width
71177
-48V B
RET B
-48V A
RET A
RS-232
(EIA/TIA-232)
LAN port
LAN LEDs
Fiber
output
monitor
port
Power
level
warning
Alarm
out
Fiber
output
port
Status
LEDs
Fiber
input
port
71176
-48V A
R A
POWER
FAIL
LOS
-48V B
R B
CISCO ONS 15216
RS-232
ALARM OUT
LAN
