Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 9 TL1 Commands
TL1 Commands and Autonomous Messages
condtype
(ccm)
Condition type identifies the type of alarm (maps to
cerent15216EdfaLogEventID). Possible condtype and
corresponding conddescr (in quotes) are:
LOS
(DWDM)
“Loss of Signal” (input power) alarm
(cerent15216EdfaAlarmLpin).
GAIN
(DWDM)
“Gain Out of Range” alarm (cerent15216EdfaAlarmGain).
LPOUT
(DWDM)
“Loss of Output Power” alarm (cerent15216EdfaAlarmLpout).
CTMP
(EQPT)
“Case Temperature Out of Range” alarm
(cerent15216EdfaAlarmCtmp).
LCRNT1
(EQPT)
“Excessive Pump1 Current” alarm
(cerent15216EdfaAlarmLcrnt1).
LCRNT2
(EQPT)
“Excessive Pump2 Current” alarm
(cerent15216EdfaAlarmLcrnt2).
LTMP1
(EQPT)
“Excessive Pump1 Temperature” alarm
(cerent15216EdfaAlarmLtmp1).
LTMP2
(EQPT)
“Excessive Pump2 Temperature” alarm
(cerent15216EdfaAlarmLtmp2).
date yyyy-mm-dd Date of origination of TL1 message.
ntfncde Notification code (maps to cerent15216EdfaAlarmPriority).
Possible values are:
CR Critical alarm.
MJ Major alarm.
MN Minor alarm.
NA No alarm.
ocrdat m-d Date (month-day) of the event occurrence (derived from
cerent15216EdfaDateAndTimeString).
ocrtm h-m-s Time (hour-minute-second) of the event occurrence (derived
from cerent15216EdfaDateAndTimeString).
sid string Source identifier uniquely identifies the source of a TL1
autonomous command.
srveff Effect on service. Possible values are:
SA Service affecting.
NSA Non-service affecting.
time hh:mm:ss Time of origination of TL1 message.
Table 9-35 RTRV-COND-ALL Syntax Description (continued)
Parameter Syntax Description
