Cisco Nexus 2000 Series Hardware Installation Guide
Chapter 1 Overview
Chassis Features
Figure 1-6 Features on the Port Side of the Cisco Nexus 2332TQ FEX Chassis
Cisco Nexus 2248TP and 2248TP-E FEX Chassis Features
The Cisco Nexus 2248TP (N2K-C2248TP) and 2248TP-E (N2K-C2248TP-E) FEX have the following
interfaces:
• 48 100/1000 BASE-T RJ-45 host-facing ports
• 4 10-Gigabit SFP+ parent-switch facing fabric ports
• 1 management or console HDMI port
The features on the fan-module side of this FEX chassis are identified in Figure 1-7, and the features on
the port side of this chassis are identified in Figure 1-8.
1 ID LED 3 Fixed 100M/1G/10GBASE-T Ports (32)
2 Status LED 4 40-Gigabit ports (4) for QSFP+ transceivers
