B-5
Cisco Nexus 2000 Series Hardware Installation Guide
Appendix B Technical Specifications
Environmental Specifications
Environmental Specifications
Table B-2 lists the environmental specifications for a FEX.
The Cisco Nexus 2332TQ, 2348TQ, 2348TQ-E, 2348UPQ, 2232PP, 2232TM, and 2248TP-ETP FEXs
can operate in a horizontal or vertical rack mount configuration.
Physical Specifications
Table B-3 lists the dimensions and weights for the Cisco Nexus Fabric Extenders.
Table B-2 Environmental Specifications for the Cisco Nexus Fabric Extender
Description Specification
Temperature, operating 32 to 104°F (0 to 40°C);
32 to 131°F (0 to 55°C) for the Cisco Nexus 2348TQ, 2348TQ-E,
and 2348UPQ
Temperature, nonoperating –4 to 158°F (–20 to 70°C);
–40 to 158°F (–40 to 70°C) for the Cisco Nexus 2348TQ,
2348TQ-E, and 2348UPQ
Humidity (RH), noncondensing 5 to 95%
Altitude 0 to 10000 ft (0 to 3000 m)
Table B-3 Physical Specifications for Installing the Cisco Nexus Fabric Extender
Cisco Nexus Fabric Extender
Dimensions (Height x Width x Depth)
1
Weight
2
Inches Centimeters
Cisco Nexus 2332TQ chassis 1.72 x 17.3 x 14.05 in. 4.37 x 43.94 x 35.69 cm 15.0 lb (6.8 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.4 lb (0.6 kg)
Cisco Nexus 2348TQ chassis 1.72 x 17.3 x 17.07 in. 4.37 x 43.94 x 43.36 cm 17.0 lb (7.7 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.4 lb (0.6 kg)
Cisco Nexus 2348TQ-E chassis 1.72 x 17.3 x 17.07 in. 4.37 x 43.94 x 43.36 cm 17.0 lb (7.7 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.4 lb (0.6 kg)
Cisco Nexus 2348UPQ chassis 1.72 x 17.3 x 14.05 in. 4.37 x 43.94 x 35.69 cm 15.5 lb (7.0 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.4 lb (0.6 kg)
Cisco Nexus 2248TP-E chassis 1.72 x 17.3 x 17.7 in. 4.37 x 43.94 x 44.96 cm 17.7 lb (8.03 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.4 lb (0.6 kg)
Cisco Nexus 2248TP chassis 1.72 x 17.3 x 17.7 in. 4.37 x 43.94 x 44.96 cm 17.7 lb (8.03 kg)
