Transceiver Specifications
Transceiver Specifications
For information about Cisco transceiver modules, refer to the Cisco Transceiver Modules Datasheet.
Airflow Optimization Accessories
This section describes the airflow optimization accessories for the Cisco Nexus FEX.
For the details of the Cisco Nexus airflow extension sleeve and the Cisco Nexus airflow vent, see
Table B-4.
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.4 lb (0.6 kg)
Cisco Nexus 2248PQ chassis 1.72 x 17.3 x 17.7 in. 4.37 x 43.94 x 44.96 cm 17.5 lb (8.0 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.8 lb (0.8 kg)
Cisco Nexus 2232PP chassis 1.72 x 17.3 x 17.7 in. 4.37 x 43.94 x 44.96 cm 18.3 lb (8.3 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.8 lb (0.8 kg)
Cisco Nexus 2224TP chassis 1.72 x 17.3 x 17.7 in. 4.37 x 43.94 x 44.96 cm 16.6 lb (1.0 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.4 lb (0.6 kg)
Cisco Nexus 2148T chassis 1.72 x 17.3 x 20.0 in. 4.37 x 43.94 x 50.8 cm 18.0 lb (8.2 kg)
Power supply
Fan tray
—
—
—
—
1.5 lb (0.7 kg)
1.5 lb (0.7 kg)
Cisco Nexus 2232TM chassis 1.72 x 17.3 x 17.7 in. 4.37 x 43.94 x 44.96 cm 18.5 lb (8.4 kg)
Power supply
Fan tray
—
—
—
—
2.2 lb (1.0 kg)
1.8 lb (0.8 kg)
1. Dimensions are presented for only the chassis rack size and service clearance requirements.
2. Combine the chassis, power supply, and fan tray weights for the overall weight of the switch to be installed. Remember to
double the power supply weights if there are two power supplies installed in the FEX.
Table B-3 Physical Specifications for Installing the Cisco Nexus Fabric Extender
Cisco Nexus Fabric Extender
Dimensions (Height x Width x Depth)
1
Weight
2
Inches Centimeters
Table B-4 Airflow Optimization Accessories
Accessories Airflow Extension Sleeve Airflow Vent
PID NXA-AIRFLOW-SLV (2200 Series)
NXA-AIRFLOW-SLV-E (2300 Series)
NXA-ACC-KIT-BAV (applies to all
models except the Cisco Nexus
2348UPQ)
Name Cisco Nexus Airflow Extension Sleeve Cisco Nexus Airflow Vent
