B-7
Cisco Nexus 2000 Series Hardware Installation Guide
Appendix B Technical Specifications
Airflow Optimization Accessories
Description Optimizes airflow in port side exhaust
airflow deployments (port side exhaust)
for alignment of port in back of rack and
extension of power supply side of
chassis to port side exhaust of rack with
airflow sleeve
Optimizes airflow in port side intake top
of rack deployments (port side intake).
Airflow vent consists of metallic cover to
place on the upper exhaust of the FEX
port side and mounting rails with snap on
holes for airflow vent.
Dimensions
(height x width x
depth)
1.72" (1RU) x 17.3" x 8.5"(fully
retracted)* or 12.9"(fully extended)*
*Adjustable depth for the FEX, between
26 and 30 inches
Vent cover is part of the mounting
hardware kit and its size is meaningless
to overall form factor of the chassis:
0.42" x 17.53" x 2.56"
Weight 5.7 lbs or 2.6 kg 0.42 lbs or 0.19 kg
Table B-4 Airflow Optimization Accessories
Accessories Airflow Extension Sleeve Airflow Vent
