Cisco Nexus 2000 Series Hardware Installation Guide
Chapter 1 Overview
Chassis Features
Figure 1-15 Fan side of the Cisco Nexus 2224TP Chassis
Figure 1-16 Rear View of the Nexus 2224TP Chassis
1 Power supply 3 Power supply (blank shown for installations with only one
power supply)
2 Fan tray (1) 4 Status (top) and ID (bottom) LEDs
1 Status (top) and ID (bottom) LEDs 3 100/1000BASE-T host-facing ports (24) for
RJ-45 connectors
2 HDMI port for a console or management
connection
4 10-Gigabit Ethernet parent-switch facing
ports (2) for SFP+ transceivers
