Cisco ME 2400 Ethernet Access Switch Hardware Installation Guide
OL-7678-01
Chapter 2 Switch Installation
Installing the Switch
Figure 2-7 Attaching Brackets for 23-Inch Racks to a Cisco ME Switch, Rear Panel Forward
Figure 2-8 Attaching Brackets for 23-Inch Telco Racks to a Cisco ME Switch
Attaching Brackets to 24-Inch Racks
These figures show attaching brackets to 24-inch racks:
• Attaching Brackets for 24-Inch Racks to a Cisco ME Switch, Front Panel Forward, Figure 2-9 on
page 2-13
• Attaching Brackets for 24-Inch Racks to a Cisco ME Switch, Rear Panel Forward, Figure 2-10 on
page 2-13
• Attaching Brackets for 24-Inch Telco Racks to a Cisco ME Switch, Figure 2-11 on page 2-13
1 Phillips flat-head screws
143308
1
1 Phillips flat-head screws
C
isco M
E
2
4
00
SE
R
IE
S
1
2
143310
1
