A-1
Cisco ME 2400 Ethernet Access Switch Hardware Installation Guide
OL-7678-01
APPENDIX
A
Technical Specifications
This appendix lists the switch technical specifications in Table A-1.
Table A-1 Technical Specifications for the Cisco ME 2400 Ethernet Access Switch
Environmental Ranges
Operating temperature 32 to 113°F (0 to 50°C)
Storage temperature –13 to 158°F (– 25 to 70°C)
Relative humidity 10 to 85% (noncondensing)
Operating altitude Up to 10,000 ft (3049 m)
Storage altitude Up to 15,000 ft (4573 m)
AC Power Requirements
AC input voltage 100 to 240 VAC
0.5 to 1 A, 50 to 60 Hz
Power consumption 25 W (typical), 30 W (maximum),
102 BTUs per hour
Power dissipation 25 W
Power rating 0.042 KVA
DC Power Requirements
DC input voltage –36 to –72 VDC, 1 to 2 A
Power consumption 25 W (typical), 30 W (maximum),
102 BTUs per hour
Power dissipation 25 W
Physical Dimensions
Weight 8.2 lb (3.72 kg)
Dimensions (H x D x W) 1.75 x 17.5 x 9.52 in. ( 4.45 x 444.5 x 24.18 cm)
