Chapter 8 Routing Power and Signal Cables
Power Requirements for the Cisco TelePresence 3000
c. Immediately connect the microphone to the codec or audio/video extension unit using the diagram
in Figure 8-8.
Figure 8-8 Discharging ESD from the Microphone Cables and Connecting the Microphone Cables and Microphones
208392
