Cisco 4351 ISR User Manual

6-67
Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers
OL-32185-02
Chapter 6 Install and Upgrade Internal Modules and FRUs
Remove and Install the Flash Memory Card
Figure 6-48 Memory Cards
Step 4
Tighten the supplied screw (see Figure 6-48) to secure the flash memory card in place.
Step 5 Replace the chassis cover. See “Remove and Replace the Chassis Cover” section on page 6-4.
1 Supplied screw 2 Supplied screw
3 Flash memory card 4 SSD mSATA storage device
5 Flash memory card connector 6 SSD mSATA connector
391828
3
4
5
6
1
1
2

Cisco 4351 ISR Specifications

General

Form Factor	Rack-mountable
Integrated Services	Yes
LAN Ports	4
Redundant power supply	Optional
Rack height	1 RU
Product Series	4000 Series
USB Ports	2
Console Port	1
Auxiliary Port	1
Operating System	Cisco IOS XE
Maximum Throughput	2 Gbps
Memory	4 GB
Flash Memory	4 GB (expandable to 16 GB)
Total concurrent sessions	1, 000, 000
Model	4351
Processor	Multi-core
Network Interfaces	GE, SFP
