SPA 500 Series IP Phone Advanced User Guide 5 | Page
3 LCD Screen Displays date and time, phone station name, line
extensions, and softkey options.
4 Line keys Indicates phone line status.
(Not available on the Cisco SPA 502G.)
When lit:
Green:
Line is idle.
Red (steady): Line is active or in use.
Red (blinking): Line is on hold.
Orange: Line is unregistered (cannot be used).
These keys can also be programmed by your phone
system administrator to perform functions such as
speed dial, call pickup, or monitoring an extension.
5 Softkey buttons Press a softkey button to perform the action shown on
the LCD screen above.
6
Press an arrow key to scroll left, right, up, or down
through items shown on the LCD screen.
7 Messages button Press to access voice mail (must be set up by your
phone system administrator).
8 Hold button Press to place a call on hold.
9 Setup button Press to access a menu to configure features.
10 Mute button Press to mute or unmute the phone. When phone is
muted, the button glows red. A flashing mute
button indicates the network connection cannot be
11 Volume button Press + to increase the volume and - to lower the
volume of the handset, headset, speaker (when the
handset is off the phone, or ringer volume (when the
handset is on the phone).
12 Headset button Push to turn the headset on or off. When the headset
is on, the button glows green.
13 Speaker button Push to turn the speaker on or off. When the speaker
is on, the button glows green.
14 Keypad Use to dial phone numbers, enter letters, and choose
menu items.
