Cisco 5520 and 8540 Wireless Controller Troubleshooting Guide
Setting up CIMC
Note Default password will be either ‘password’ or ‘Cisco1234’. You can change this via the username
command
CIMC Configurations that are required for reliable WLC operation
Note Once the user logs in to CIMC the following should not be changed. This will cause issues for WLC
operation.
• Do not change the NIC mode to shared. It should be in dedicated mode
• Do not change the FlexFlash Mode
• Do not change the SSD/Virtual disk settings
• BIOS parameters should not be changed
Expectations when logged in via CIMC
• FlexFlash is configured for RAID but only one flash is populated this causes CIMC to show the
FlexFlash as degraded.We can safely dis-regard the FlexFlash degradation warning in our case.
• Expect to see only one CPU populated
• Do not configure Software Raid on SSD
IMM Chassis Command reference
>show imm chassis
bios Fetch Chassis BIOS information
current Fetch Chassis Current information
fan Fetch Chassis FAN information
mac Fetch Chassis MAC information
memory Fetch Chassis Memory information
power-supply Fetch Chassis Power Supply information
sol-info Fetch Serial Over Lan information
temperature Fetch Chassis Temperature information
Some Example Outputs
>show imm chassis bios
BIOS Information
Vendor: Cisco Systems, Inc.
Version: C240M4.2.0.4a.0.042220151400
Release Date: 04/22/2015
>show imm chassis fan

Cisco 5520 Specifications

General

Maximum Access Points	1500
Maximum Clients	20000
Form Factor	1RU
Product Series	Cisco 5500 Series
Memory	32 GB
Flash Memory	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-4°F to 149°F (-20°C to 65°C)
Model	Cisco 5520
Ports	8 x 1GE
Redundancy	N+1
Management	CLI
Wireless Standard	802.11ac
Humidity	10% to 95% non-condensing
