Cisco Network Convergence System 6000 Series Routers Site Planning Guide
OL-29236-02
Chapter 1 Cisco NCS 6008 Chassis
Figure 1-2 shows the rear view of the Cisco NCS 6008 chassis.
Figure 1-2 Rear View of the Cisco NCS 6008 Chassis
1 Power input feeds (AC or DC) 3 Card cage with slots for FCs and RP cards
2 Air exhaust plenum
304092
2
3
1
