2-6
Cisco Network Convergence System 6000 Series Routers Site Planning Guide
OL-29236-02
Chapter 2 Power and Cooling
DC Power Systems
Figure 2-3 90-Degree DC Input Power Cable Lug
Note Use local electrical codes for clearance requirements when using power lugs to ensure safe operation.
.25±.04
.63±.02
.55±.04
.27±.02 DIA
(2)PLS
304199
1.25±.04
1.05±.04
1.45
REF
1.74 REF
.28±.01
.38±.01
90°+/- 5°
.09±.01
Wire inspection
window
Beveled wire
entry
Color coded
barrel markings
