1-12
Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide
OL-2239-05
Chapter 1 Overview of Cisco uBR7200 Series Software
Cisco uBR7200 Series Chassis Overview
For more information, refer to the following resources on Cisco.com:
• Network Processing Engine and Network Services Engine Installation and Configuration Guide
• Memory Replacement Instructions for the Network Processing Engine or Network Services Engine and
Input/Output Controller
I/O Controllers
The Cisco uBR7200 series universal broadband routers support the following input/output (I/O)
controllers:
• UBR7200-I/O-2FE/E input/output controller
– Features two Fast Ethernet ports and one Ethernet port.
– Equipped with 2 RJ-45 receptacles for 10/100 Mbps operation.
– Supported for the Cisco uBR7246VXR router.
– The Cisco IOS Release 12.1(10)EC boot helper image [ubr7200-boot-mz.12.1-10.EC] must be
used on this controlle.r
• UBR7200-I/O-FE
– Features one Fast Ethernet port.
– Equipped with an MII receptacle and an RJ-45 receptacle for use at 100 Mbps full-duplex or
half-duplex operation.
– Only one receptacle can be configured for use at a time.
– Supported for Cisco uBR7223, Cisco uBR7246, and Cisco uBR7246 VXR routers.
– The 12.0(15)SC [ubr7200-boot-mz.12.0-15.SC] boot helper image is recommended for this
controller.
• UBR7200-I/O
– Has no Fast Ethernet port.
– Supported for Cisco uBR7223, Cisco uBR7246, and Cisco uBR7246 VXR routers.
– The 12.0(15)SC [ubr7200-boot-mz.12.0-15.SC] boot helper image is recommended for this
controller.
Note The Single-Port Fast Ethernet I/O Controller (UBR7200-I/O-FE) reached its End of Sale (EOS) point
on June 30, 2003. For details, see the Addendum to Product Bulletin, No. 1725, available at the
following location on Cisco.com:
http://www.cisco.com/en/US/products/hw/cable/ps2217/prod_eol_notice09186a00800a470d.html
Note Do not use the 12.1(10)EC boot helper image with the UBR7200-I/O-FE and UBR7200-I/O
controllers.
