D-1
Cisco uBR7200 Series Universal Broadband Router Software Configuration Guide
78-5897-03
APPENDIX
D
Frequency Allocation for the Cisco uBR7200
Series Universal Broadband Routers
Table D-1 provides information on NTSC 6-MHz channel bands. Table D-2 provides information on the
Phase Alternating Line (PAL) and Systeme Electronique Couleur Avec Memoire (SECAM) 8-MHz
channel bands.
Ta b l e D-1 NTSC Cable Television Channels and Relative Frequencies in MHz
Channel Number Bandwidth Video Carrier Color Carrier Audio Carrier
T 7 5.75 - 11.75 7 10.58 11.5
T 8 11.75 - 17.75 13 16.58 17.5
T9 17.75-23.75 19 22.58 23.5
T10 23.75-29.75 25 28.58 29.5
T11 29.75-35.75 31 34.58 35.5
T12 35.75-41.75 37 40.58 41.5
T13 41.75-47.75 43 46.58 47.5
TV-IF 40.0-46.0 45.75 42.17 41.25
2-2 54.0-60.0 55.25 58.83 59.75
3-3 60.0-66.0 61.25 64.83 65.75
4-4 66.0-72.0 67.25 70.83 71.75
5-5 76.0-82.0 77.25 80.83 81.75
6-6 82.0-88.0 83.25 86.83 87.75
FM 88.0-108.0
A-5-95 90.0-96.0 91.25 94.83 95.75
A-4-96 96.0-102.0 97.25 100.83 101.75
A-3-97 102.0-108.0 103.25 106.83 107.75
A-2-98 108.0-114.0 109.25 112.83 113.75
A-1-99 114.0-120.0 115.25 118.83 119.75
A-14 120.0-126.0 121.25 124.83 125.75
B-15 126.0-132.0 127.25 130.83 131.75
C-16 132.0-138.0 133.25 136.83 137.75
