1-4
Cisco Wide Area Virtualization Engine 7541, 7571, and 8541 Hardware Installation Guide
Chapter 1 Introducing the Cisco Wide Area Virtualization Engine 7541, 7571, and 8541
Hardware Features
Figure 1-3 Back Panel Components
Figure 1-4 shows the back panel LEDs.
Figure 1-4 Back Panel LEDs
Table 1-2 describes the back panel LEDs and their functions.
1 Power supplies (0 and 1, left to
right)
2 Fans
• Large: 1 - 3 (right to left)
• Small: 4 - 9 (right to left,
bottom row first)
1 2
2
1 2 9 10 115 6 7
43
8
