DescriptionParameter

Allows you to select Speed and duplex of the

Computer (access) port.

• Auto

• 10MB half

• 10MB full

• 100 MB half

• 100MB full

• 100 half

• 1000 full

PC Port Config

Specifies if PC port is enabled. Options are Yes or

No.

PC PORT Enable

Adds the ability to port mirror on the PC port. When

enabled, you can see the packets on the phone. Select

Yes to enable PC port mirroring and select No to

disable it.

Enable PC Port Mirror

Specify the syslog server name and port. This feature

specifies the server for logging IP phone system

information and critical events. If both Debug Server

and Syslog Server are specified, Syslog messages are

also logged to the Debug Server.

Syslog Server

Cisco IP Phone 7800 Series Multiplatform Phones Administration Guide

229

Cisco IP Phone Troubleshooting

Optional Network Configuration
