Cisco 7841 Installation Guide

Installation Guide for Cisco IP Phone with Multiplatform Firmware
27
Wall Mount Your 8800 Series Phones
Wall Mount Your Phone
Plug in the Ethernet cable, and the power adapter
(optional).
3
Attach the assembly to the wall bracket by in-
serting the tabs of the wall brackets into the slots
on the phone bracket.
4
Remove an 8800 Phone from the Wall Mount
447347
447348
447349
3
2
1
1
2
1
2
Use a screw driver or other device to disengage the tabs.
3
Lift the phone to release it from the wall bracket.
Pull the phone toward you.

Cisco 7841 Specifications

General

Ethernet Switch	Yes
Lines	4
Headset Port	Yes
Wall Mountable	Yes
Display	3.5-inch grayscale display
Audio	Wideband audio
PoE	IEEE 802.3af
Speakerphone	Full-duplex
Ethernet Ports	2 x 10/100/1000
Headset Jack	RJ9
Protocols	SIP
Codec Support	G.711, G.722, G.729, iLBC
Mounting	Desk or wall
Weight	1 kg
