See the Cisco Unified Communications Manager Administration Guide, “Cisco Unified IP Phone Services
Configuration” chapter.
Step 9
Add user information by configuring required fields:
•
Name (last)
•
User ID
•
Password (for Cisco Unified Communications Manager web pages)
•
PIN (for use with Extension Mobility and Personal Directory)
Adds user information to the global directory for Cisco Unified Communications Manager.
See the Cisco Unified Communications Manager Administration Guide, “End User Configuration” chapter,
and Cisco Unified Communications Manager User Addition.
If your company uses a Lightweight Directory Access Protocol (LDAP) directory to store information on
users, you can install and configure Cisco Unified Communications to use your existing LDAP directory, see
Corporate and Personal Directory Setup.
Step 10
Add a user to a user group.
Assigns users a common list of roles and permissions that apply to all users in a user group. Administrators
can manage user groups, roles, and permissions to control the level of access (and, therefore, the level of
security) for system users.
See the Cisco Unified Communications Manager Administration Guide, “User Group Configuration” chapter.
Step 11
Associate a user with a phone (optional).
Provides users with control over their phone such as forwarding calls or adding speed-dial numbers or services.
Some phones, such as those in conference rooms, do not have an associated
user.
Note
See the Cisco Unified Communications Manager Administration Guide, “End User Configuration” chapter.
Cisco Unified IP Phone Installation
After you add the phones to the Cisco Unified Communications Manager database, you can complete the
phone installation. You can install the phones at the desired locations, or you can give the phone users the
information they need to perform the installation. The Cisco Unified IP Phone Installation Guide, which is
available at http://www.cisco.com/en/US/products/hw/phones/ps379/prod_installation_guides_list.html,
provides directions for connecting the phone foot stand, handset, cables, and other accessories.
Upgrade the phone to the current firmware image before installation. For information about phone upgrades,
see the Readme file for your phone model located at:
http://www.cisco.com/cgi-bin/tablebuild.pl/ip-7900ser
Note
After the phone connects to the network, the phone startup process begins, and the phone registers with
Cisco Unified Communications Manager. To complete phone installation, configure the network settings on
the phone depending on whether you enable or disable DHCP service.
Cisco Unified IP Phone 7931G Administration Guide for Cisco Unified Communications Manager 9.0 (SCCP
and SIP)
26
Cisco Unified IP Phone 7931G
Cisco Unified IP Phone Installation

Cisco 7931G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Wall mountable	Yes
Electromagnetic compatibility	FCC Part 15 (CFR 47) Class B, ICES-003 Class B, EN55022 Class B, CISPR22 Class B, AS/NZS CISPR 22 Class B, CISPR 24, VCCI Class B, EN55024, EN 50082-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1
Wi-Fi	No
Networking standards	IEEE 802.1Q, IEEE 802.1af, IEEE 802.1p
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	DHCP, TFTP, CDP
Lines quantity	24 lines
Phonebook capacity	- entries
Number of VoIP accounts	-
Voice codecs	G.711a, G.729A, G.729B, G.729ab
Volume control	Digital
Display resolution	192 x 64 pixels
Display number of lines	3 lines
Display number of colors	Monochrome
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Safety	(UL) 60950, (CSA) C22.2 No. 60950, EN 60950, IEC 60950, AS/NZS60950, TS 001
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	229 mm
Width	203 mm
Height	178 mm
Weight	1360 g
