3-7
Cisco Unified IP Phone 7965G and 7945G Administration Guide for Cisco Unified Communications Manager 6.1(3)
OL-17755-01
Chapter 3 Setting Up the Cisco Unified IP Phone
Installing the Cisco Unified IP Phone
To install a Cisco Unified IP Phone, perform the following steps, shown in Table 3-1:
Ta b l e 3-1 Installing the Cisco Unified IP Phone 7965G and 7945G
Configuration Step and Notes Reference
Step 1
Connect the handset to the Handset port.
—
—
Step 2
Connect a headset to the Headset port.
Optional. You can add a headset later if you do not connect one
now.
See the “Headset” section on
page 3-4 for supported headsets.
Step 3
Connect a wireless headset.
Optional. You can add a wireless headset later if you do not want to
connect one now.
Refer to the wireless headset
documentation for information.
Step 4
Connect the power supply to the Cisco DC Adapter port.
Optional.
See the “Providing Power to the
Phone” section on page 2-3.
Step 5
Connect a straight-through Ethernet cable from the switch to the
10/100/1000 SW port.
Each Cisco Unified IP Phone ships with one Ethernet cable in the
box.
You can use either Category 3/5/5e/6 cabling for 10 Mbps
connections, but you must use Category 5/5e/6 for 100 Mbps
connections and Category 5e/6 for 1000 Mbps connections.
See the “Network and Access
Ports” section on page 3-4 for
guidelines.
Step 6
Connect a straight-through Ethernet cable from another network
device, such as a desktop computer, to the 10/100/1000 PC port.
Optional. You can connect another network device later if you do
not connect one now.
You can use either Category 3/5/5e/6 cabling for 10 Mbps
connections, but you must use Category 5/5e/6 for 100 Mbps
connections and Category 5e/6 for 1000 Mbps connections.
See the “Network and Access
Ports” section on page 3-4 for
guidelines.
