Connecting Your Phone
Your system administrator will likely connect your new Cisco Unified IP Phone to the corporate IP
telephony network. If that is not the case, refer to the graphic and table below to connect your phone.
1
DC adaptor port (DC48V)
6
Handset port
2
AC-to-DC power supply
7
Headset port
3
AC power cord
8
External speaker port
4
Network port (10/100
1
SW)
1. Your phone may show 10/100/1000.
9
Microphone port
5
Access port (10/100
1
PC)
10
Footstand button
1
8
9
113951
AUX 10/100/1000 SW 10/100/1000 PC
DC48V
9
9
10
8
7
5
4
3
2
6
