An Overview of Your Phone
Cisco Unified IP Phone 7970 Series Phone Guide for Cisco Unified Communications Manager 6.1(3) -21
Choosing Touchscreen Items
There are three ways to choose items on your phone’s touchscreen.
Cleaning and Maintaining the Touchscreen
You can use the Display button to disable and enable the touchscreen. The Display button
illuminates to indicate changes in touchscreen status:
Green, steady—Touchscreen is in sleep mode
Green, flashing—Touchscreen is disabled
5
Call activity
area
Displays current calls per line, including caller ID, call duration, and call state
for the highlighted line (standard view). Items in this area are touch-sensitive.
See
Understanding Line and Call Icons, page 19, and Viewing Multiple Calls,
page 33.
6
Phone tab Indicates call activity. Press this tab to return to the call activity area, if needed.
7
Feature tabs Each indicates an open feature menu. Tabs are touch-sensitive. See
Understanding Feature Buttons and Menus, page 22.
To choose a
touchscreen item...
Do this...
By touch Press (or tap) touch-sensitive items on the touchscreen with your fingertip.
Use only your fingertip to press the touchscreen, as using any other objects
could damage the display. Be aware that pressing a phone number can cause the
phone to dial the number.
By item number Press the corresponding number on your keypad. For example, press 4 to
choose the fourth item in a menu.
By scrolling Press the Navigation button to highlight an item. Press a softkey to finish the
action, or tap the item on the touchscreen with your fingertip.
If you want to... Then...
Disable the touchscreen
for cleaning
Press and hold for more than one second. flashes.
The screen remains disabled for about a minute, unless you enable it.
