PurposeCommand or Action
- Entering no exits the configuration session and returns the router
to EXEC mode without committing the configuration changes.
- Entering cancel leaves the router in the current configuration
session without exiting or committing the configuration changes.
•
Use the commit command to save the configuration changes to
the running configuration file and remain within the configuration
session.
The following example shows how to identify a satellite optical shelf and how to connect to it:
nv satellite 100
type ons15454-m6
ip address 1.2.3.4
vrf mgmt
username CISCO15 password otbu+1
serial abcdrstv
Provisioning an Optical Application
This task describes how to declare which optical application (transponder or muxponder) configuration to be
used. The location of the trunk and client ports on the satellite optical shelf and the connectivity details between
the host and the shelf can also be specified.
For each link from a host to an optical shelf, specify the signal mode at the router and client ports in the
relevant controller configuration. The signal can be in Ethernet mode or it can include an Optical Transport
Network (OTN) encapsulation. By default, the ports are in Ethernet mode. Ensure that the configuration for
all router and client ports is consistent.
The following shows the preexisting configuration that adds OTN encapsulation to the router port:
controller dwdm 0/0/0/0
g709 enable
To run the following configuration CLIs, read and write access in the 'ethernet-services' task ID is required.
You can skip the satellite optical shelf identity configuration steps in the following procedure if they are
already configured.
Note
Step 1
configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters global configuration mode.
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
117
Configuring the Satellite nV Optical Shelf System
Provisioning an Optical Application
