PurposeCommand or Action
Creates a multilink interface bundle with the specified
bundle ID.
bundle id bundle-id
Example:
RP/0/RSP0/CPU0:router(config-if)# bundle id 2
Step 11
Enters the satellite network virtualization (nV)
configuration submode.
nv
Example:
RP/0/RSP0/CPU0:router(config-if)# nv
Step 12
Specifies an interface as an Interface Control Plane
Extender(ICPE) inter-chassis link (ICL).
satellite-fabric-link satellite satellite_id
Example:
RP/0/RSP0/CPU0:router(config-if)#
satellite-fabric-link satellite 100
Step 13
The Interface Control Plane Extender(ICPE)
infrastructure has a mechanism to provide the
Control Plane of an interface physically
located on the Satellite device in the local
Cisco IOS XR software.
Note
Configures the remote satellite ports 0 to 5.
remote-portsinterface_type remote_subslot
Example:
RP/0/RSP0/CPU0:router(config-satellite-fabric-link)#
remote-ports GigabitEthernet 0/0/0-5
Step 14
Attaches a policy map to an output interface to be used
as the service policy for that interface.
service-policy output policy-map
Example:
RP/0/RSP0/CPU0:router(config-satellite-fabric-link)#
service-policy output policy4
Step 15
commit
Step 16
Returns the router to global configuration mode.exit
Example:
RP/0/RSP0/CPU0:router(config-if)# exit
Step 17
commit
Step 18
Offloading Service-policy on L2 Fabric Physical SFL
Perform these tasks to offload the service-policy on L2 Fabric physical Satellite Fabric Link (SFL). This
procedure offloads the service-policy in the egress direction of SFL.
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
88
Configuring QoS on the Satellite System
Offloading Service-policy on L2 Fabric Physical SFL
