Cisco A9K-SIP-700 System Configuration Guide

SUMMARY STEPS
1.
configure
2.
class-map [type qos] [match-any] [match-all] class-map-name
3.
match qos-group [qos-group-value1]
4.
end-class-map
5.
policy-map [ type qos ] policy-name
6.
class class-name
7.
bandwidth {bandwidth [units] | percent value}
8.
exit
9.
end-policy-map
10.
interface type interface-path-id
11.
encapsulation dot1qvlan-identifier
12.
nv
13.
satellite-fabric-link satellite satellite_id
14.
remote-portsinterface_type remote_subslot
15.
service-policy output policy-map
16.
commit
DETAILED STEPS
PurposeCommand or Action
configure
Step 1
Creates a class map to be used for matching packets to
the class specified and enters the class map
configuration mode.
class-map [type qos] [match-any] [match-all]
class-map-name
Example:
RP/0/RSP0/CPU0:router(config)# class-map match-any
class5
Step 2
If you specify match-any, one of the match criteria
must be met for traffic entering the traffic class to be
classified as part of the traffic class. This is the default.
If you specify match-all, the traffic must match all the
match criteria.
Specifies service (QoS) group values in a class map to
match packets.
match qos-group [qos-group-value1]
Example:
RP/0/RSP0/CPU0:router(config-cmap)# match qos-group
5
Step 3
•
qos-group-value identifier argument is specified
as the exact value or range of values from 0 to 63.
•
Up to eight values (separated by spaces) can be
entered in one match statement.
•
match qos-groupcommand is supported only for
an egress policy.
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
89
Configuring QoS on the Satellite System
Offloading Service-policy on L2 Fabric Physical SFL
