remote-ports <interface-id>
!
!
nv
satellite <id>
type <type>
device-name <name>
redundancy
host-priority <0-255>
!
serial-number <serial-number>
!
Dual-Home for Multiple Satellites with Single Physical ICLs on Both Hosts
and Satellites
Dual Home Configuration for SAT1
When you use either a manual IP address or an IPv4 unnumbered loopback address for the ICL, the IP
address must be different on both the hosts.
Note
Host 1:
interface TenGigE0/1/1/23.100
ipv4 point-to-point
ipv4 address 100.100.1.101 255.255.255.0
encapsulation dot1q 100
nv
satellite-fabric-link satellite 100
redundancy
iccp-group 1
!
remote-ports GigabitEthernet 0/0/0-35
!
!
!
Host 2:
interface TenGigE0/1/1/2.100
ipv4 point-to-point
ipv4 address 100.100.1.102 255.255.255.0
encapsulation dot1q 120
nv
satellite-fabric-link satellite 100
redundancy
iccp-group 1
!
remote-ports GigabitEthernet 0/0/0-35
Dual Home Configuration for SAT2
Host 1:
Host1:
interface TenGigE0/1/1/23.200
ipv4 point-to-point
ipv4 address 100.100.1.101 255.255.255.0
encapsulation dot1ad 100
nv
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
68
Configuring the Satellite Network Virtualization (nV) System
Dual-Home for Multiple Satellites with Single Physical ICLs on Both Hosts and Satellites
