PurposeCommand or Action
Configures the ICPE inter-chassis link for the specified
satellite.
satellite-fabric-link satellite <id>
Example:
RP/0/RSP0/CPU0:router(config-interface)#
satellite-fabric-link satellite 100
Step 3
(Optional) Configures the IPv4 point to point address.ipv4 point-to-point
Example:
RP/0/RSP0/CPU0:router(config-interface)# ipv4
point-to-point
Step 4
(Optional) Configures the IPv4 loopback address on the
interface.
ipv4 unnumbered loopback0
Example:
RP/0/RSP0/CPU0:router(config-interface)# interface
unnumbered loopback0
Step 5
Configures the ICCP redundancy group. In order to
configure multiple ICCP redundancy groups, repeat steps
6 through 10 with a different redundancy group number.
redundancy iccp-group
Example:
RP/0/RSP0/CPU0:router(config-interface)# redundancy
iccp-group 1
Step 6
(Optional) Configures the minimum number of preferred
satellite fabric bundle-ether links. To configure this
minimum preferred links num
Example:
RP/0/RSP0/CPU0:router(config-satellite-fabric-link)#
redundancy minimum preferred links 2
Step 7
parameter, the interface must be a bundle-ether interface.
If you do not enable this parameter on any host, then it is
assumed as 0 by default on that host. Hence, the decision
(or)
of failover is judged using that value. The range is 1 to
64.
RP/0/RSP0/CPU0:router(config-satellite-fabric-link)#
redundancy
You can either go to the redundancy mode to
configure minimum preferred links or you can
specify redundancy keyword before configuring
the minimum preferred links.
Note
RP/0/RSP0/CPU0:router(config-nV-red)# minimum
preferred links 2
Configures the LDP neighbor.member neighbor 9.9.9.9
Example:
RP/0/RSP0/CPU0:router(config-interface)# member
neighbor 9.9.9.9
Step 8
(Optional) Configures the backbone interface for the PE
isolation.
backbone interface interface_type
Example:
RP/0/RSP0/CPU0:router(config-interface)# backbone
interface TenGigE0/1/0/3
Step 9
Configures the remote satellite ports 0 to 30.
remote-ports interface-type
Example:
RP/0/RSP0/CPU0:router(config-int-nv)# remote-ports
GigabitEthernet 0/0/0-30
Step 10
Saves configuration changes.end or commit
Step 11
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
40
Configuring the Satellite Network Virtualization (nV) System
Configuring the Inter-Chassis Links and IP Connectivity
