Table 8: Slot and Port Locations for the 2-Port Channelized OC-12/DS0 SPA
DescriptionCall Out Number
Slot 01
SPA in Subslot 02
Ports 0/0/0/0 and 0/0/0/13
The following figure shows the slot, subslot, and port locations for the 2-Port Channelized OC-12/DS0 SPA
on a Cisco ASR 9010 10-slot chassis.
Figure 5: Slot, Subslot, and Port Locations for the 2-Port Channelized OC-12/DS0 SPA on a Cisco ASR 9010 Chassis
Table 9: Slot and Port Locations for the 2-Port Channelized OC-12/DS0 SPA in Slot 3
DescriptionCall Out Number
Slot 31
Subslot 0, Port 3/1/0/0 to 3/1/0/12
Ports of RSP1 in Slot 53
Cisco ASR 9000 Series Aggregation Services Router SIP and SPA Hardware Installation Guide
7
Overview: Cisco ASR 9000 Series Router SPA Interface Processors
SPA Interface Addresses on the Cisco ASR 9000 SIP-700
