Chapter 2 Installation Overview
Installation Summary
Figure 2-4 Power Module
Figure 2-5 Grounding Block
Installation Summary
Caution You should read and carefully follow the installation instructions before connecing the system to its
power source. The access point/bridge and power injector can be damaged by incorrect power
application.
Note To meet regulatory restrictions, the external antenna access point/bridge unit and the external antenna
must be professionally installed. The network administrator or other IT professional responsible for
installing and configuring the unit is a suitable professional installer. Following installation, access to the
unit should be password protected by the network administrator to maintain regulatory compliance.
During the installation of the access point/bridge, you will perform the following operations:
• Connect a user-supplied Category 5 Ethernet cable from your wired LAN network to the power
injector.
1 48-VDC power output cable 3 AC power cord
2 Power module
1
2
3
88829
1 F-type coaxial connectors 2 Ground wire lug
88830
1 1 2
