Chapter 3 Mounting and Alignment Overview
LEDs
The Install LED provides bridge association status during installation mode as shown in Table 3-2.
Use the Install LED to determine when the bridge successfully associates with a remote bridge and to
verify its mode of operation. After association, the other three LEDs indicate signal strength.
The startup and association sequence depends on the access point/bridge configuration, which can be
one of the following types:
• Default—The access point/bridge attempts to associate with a root bridge for 60 seconds. If it does
not associate with a root bridge, it attempts to associate with a non-root bridge.
• Preconfigured bridge mode—The unit attempts to associate with a remote bridge in the configured
mode, either root or non-root. Because there are no timeouts, it is easier to align the antenna.
• Preconfigured access point or workgroup bridge modes—the bridge Install LED does not operate.
Table 3-2 Install LED Status
Install LED Status Bridge State
Off Self test Startup.
Amber blinking Non-root, searching Not associated (non-root mode). The
access point/bridge attempts to associate
with a root bridge for 60 seconds
1
.
1. Preconfigured bridges search indefinitely.
Amber Non-root, associated Associated (non-root mode).
Green blinking Root, searching Not associated (root mode). The access
point/bridge attempts to associate with a
non-root bridge indefinitely.
Green Root, associated Associated (root mode).
Red Error Overvoltage or overcurrent error
2
2. Disconnect power to the power injector, wait approximately 1 minute, and reconnect power. If error
continues, contact technical support.
