Installing the Power Cord Retainer (Optional)
This section applies only to the Catalyst 2960-X switches.Note
The power cord retainer is optional (part number [PWR-CLP=]). You can order it when you order your switch,
or you can order it later from your Cisco representative.
Procedure
Step 1
Choose the sleeve size of the power cord retainer based on the thickness of the cord. The smaller sleeve can
be snapped off and used for thin cords.
Step 2
Slide the retainer around the AC power cord, and pass it around the loop on the switch.
Figure 22: Inserting the Retainer Through the Lanced Loop
Sleeve for thinner power cords3AC power cord1
Loop4Power cord retainer2
Catalyst 2960-X and 2960-XR Switch Hardware Installation Guide
OL-28309-02 43
Switch Installation
Installing the Power Cord Retainer (Optional)
