SUMMARY STEPS
1.
enable
2.
configure terminal
3.
interface interface-id
4.
storm-control {broadcast | multicast | unicast} level {level [level-low] | bps bps [bps-low] | pps pps
[pps-low]}
5.
storm-control action {shutdown | trap}
6.
end
7.
show storm-control [interface-id] [broadcast | multicast | unicast]
8.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode. Enter your password if prompted.enable
Step 1
Example:
Switch> enable
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 2
Specifies the interface to be configured, and enter interface configuration mode.
interface interface-id
Example:
Switch(config)# interface
gigabitethernet1/0/1
Step 3
Configures broadcast, multicast, or unicast storm control. By default, storm control
is disabled.
storm-control {broadcast | multicast
| unicast} level {level [level-low] | bps
bps [bps-low] | pps pps [pps-low]}
Step 4
The keywords have these meanings:
Example:
Switch(config-if)# storm-control
unicast level 87 65
•
For level, specifies the rising threshold level for broadcast, multicast, or
unicast traffic as a percentage (up to two decimal places) of the bandwidth.
The port blocks traffic when the rising threshold is reached. The range is
0.00 to 100.00.
•
(Optional) For level-low, specifies the falling threshold level as a percentage
(up to two decimal places) of the bandwidth. This value must be less than
or equal to the rising suppression value. The port forwards traffic when
traffic drops below this level. If you do not configure a falling suppression
level, it is set to the rising suppression level. The range is 0.00 to 100.00.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 393
Configuring Port-Based Traffic Control
Configuring Storm Control and Threshold Levels
