Cisco Catalyst 2960-X Series User Manual

Environmental Specifications 69
Specifications for the Catalyst 2960-X Switches 70
Specifications for the Catalyst 2960-XR Switches 74
APPENDIX B Connector and Cable Specifications 77
Connector Specifications 77
10/100/1000 Ports (Including PoE) 77
SFP Module Connectors 78
Cables and Adapters 78
SFP Module Cables 78
Cable Pinouts 80
Console Port Adapter Pinouts 81
APPENDIX C Configuring the Switch with the CLI-Based Setup Program 83
Accessing the CLI Through Express Setup 83
Accessing the CLI Through the Console Port 83
Connecting the RJ-45 Console Port 84
Connecting the USB Console Port 85
Installing the Cisco Microsoft Windows USB Device Driver 86
Installing the Cisco Microsoft Windows XP USB Driver 86
Installing the Cisco Microsoft Windows 2000 USB Driver 87
Installing the Cisco Microsoft Windows Vista and Windows 7 USB Driver 87
Uninstalling the Cisco Microsoft Windows USB Driver 87
Uninstalling the Cisco Microsoft Windows XP and 2000 USB Driver 87
Using the Setup.exe Program 88
Using the Add or Remove Programs Utility 88
Uninstalling the Cisco Microsoft Windows Vista and Windows 7 USB Driver 88
Entering the Initial Configuration Information 89
IP Settings 89
Completing the Setup Program 89
Catalyst 2960-X and 2960-XR Switch Hardware Installation Guide
vi OL-28309-02
Contents

Cisco Catalyst 2960-X Series Specifications

General

Operating System	Cisco IOS
Form Factor	Rack-mountable
RAM	512 MB
Model	2960-X Series
Ports	48 x Gigabit Ethernet
Uplink Interfaces	Optional 1G or 10G uplinks
Switching Capacity	Up to 160 Gbps
Stacking	Yes, up to 8 switches
Power over Ethernet	PoE+ (IEEE 802.3at) available on selected models
Dimensions	4.4 x 45 x 28.2 cm (1.73 x 17.7 x 11.1 in)
Weight	5.4 kg
VLANs	4096
Jumbo Frame Support	9198 bytes
Power Supply	100-240VAC, 50-60 Hz
Features	Layer 2 and Layer 3 features, QoS, IPv6 support
Software	LAN Base
Operating Temperature	0 to 45°C (32 to 113°F)
