IN-5
Catalyst 3550 Multilayer Switch Hardware Installation Guide
78-11358-03
Index
M
main disconnecting device warning C-9 to C-10
Mode button 1-10
mounting, table or shelf 2-22
mounting, wall mounting 2-19
mounting brackets
attaching
2-9 to 2-15
rack-mount 2-16
MT-RJ connector B-4
See also 100BASE-FX ports
N
noise, electrical 2-6
O
overtemperature warning C-10 to C-12
P
packing list 2-7
PC, connecting to switch 2-41
performance problems, solving 3-2
pinouts
10/100 ports
B-5
1000BASE-T GBIC port B-5
1000BASE-X GBIC ports B-5
adapters B-10 to B-11
console port B-11
crossover cables
four twisted-pair, 10/100 ports
B-8
four twisted-pair, 1000BASE-T ports B-9
two twisted-pair, 10/100 ports B-7
GBIC ports B-6
RJ-45-to-DB-25 terminal adapter B-11
RJ-45-to-DB-9 terminal adapter B-10
rollover cable B-10 to B-11
straight-through cables
four twisted-pair, 10/100 ports
B-8
four twisted-pair, 1000BASE-T ports B-9
two twisted-pair, 10/100 ports B-7
port LEDs 1-17 to 1-20
port modes
changing
1-10
LEDs 1-17
See also Mode button
ports
10/100
1-8
10/100/1000 1-5
1000BASE-T GBIC 1-9
1000BASE-X GBIC 1-9
GigaStack GBIC 1-9
numbering of 10/100 1-8
numbering of 10/100/1000 1-8
