Chapter 2 Installing and Starting the Switch
Installing the GBIC Modules
Installing the GBIC Modules
Figure 2-7, Figure 2-8, and Figure 2-9 show how a GBIC module is inserted into
a GBIC module slot on the switch. For detailed instructions on installing,
removing, and cabling the GBICs (1000BASE-X module, 1000BASE-T module,
or the GigaStack module), refer to your GBIC documentation.
Note GBIC modules are not factory-installed on this switch, but you can order
GBIC modules separately.
Figure 2-7 Installing a 1000BASE-X GBIC Module in the Switch
1
2
C
atalyst 3550
6
7
8
9
1
0
1
1
50384
Metal flap door
GBIC module slot1000BASE-X
GBIC module
