Cisco Catalyst 4500 Series Overview

Chapter 1 Module Overview and Specifications
Supervisor Engines
1-10
Catalyst 4500 Series Module Installation Guide
78-13267-06
Ethernet Management Port
The WS-X4012 supervisor engine has a 10BASE-T Ethernet management port.
The WS-X4516-10GE and WS-X4013+10GE supervisor engine modules have a
10/100/1000BASE-T Ethernet management port.The other supervisor engine
modules have a 10/100BASE-T Ethernet management port. Supervisor engines
use an RJ-45 connector on the front panel with a link status LED. For the location
of the port, see Figure 1-1 (WS-X4012), Figure 1-2 (WS-X4013), Figure 1-3
(WS-X4013+), Figure 1-4 (WS-X4013+TS), Figure 1-5 (WS-X4013+10GE),
Figure 1-6 (WS-X4014), Figure 1-7 (WS-X4515), Figure 1-8 (WS-X4516), or
Figure 1-9 (WS-X4516-10GE).
TCP/IP-based management services available through inband access also are
provided through this port (Telnet and SNMP). This management port also
supports image download.
Note The 10BASE-T and 10/100BASE-T Ethernet management ports are for network
management only. These ports do not support network switching.
Console Port
The console port allows you to perform the following functions:
• Configure the switch from the CLI
• Monitor network statistics and errors
• Configure SNMP agent parameters
• Download software updates to the switch or distribute software images
residing in Flash memory to attached devices
The Catalyst 4003 console port is a DCE DB-25 receptacle, which supports a
DCE EIA/TIA-232 interface. The console port is an RJ-45 receptacle on the
Catalyst 4006, 4503, 4506, and 4507.
Note EIA/TIA-232 was known as recommended standard RS-232 before its acceptance
as a standard by the Electronic Industries Association (EIA) and
Telecommunications Industry Association (TIA).

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
