1-13
Catalyst 4500 Series Module Installation Guide
78-13267-06
Chapter 1 Module Overview and Specifications
Ethernet and Fast Ethernet Switching Modules
Figure 1-10 WS-X4124-RJ45 24-Port 10/100BASE-TX Fast Ethernet Switching Module
Number of ports 24
Connector type RJ-45 (See Figure 2-1 on page 2-2.)
Cable type UTP
1
or FTP
1. UTP = unshielded twisted-pair
Specification Description
113135
