Cisco Catalyst 9400 Series User Manual

SpecificationItem
• Chassis (airflow direction when facing the front of the chassis)
• Standard Rack Mount (With or without shelf brackets)—Right to left
• NEBS-Compliant Rack Mount—Front to back
• Power supply—Front to back
Airflow
Operating—5G 11ms (Half-sine)
Nonoperating and storage— 15G 11ms (Half-sine)
Shock
• Operating— 0.15G (10Hz-500Hz)
• Nonoperating and storage— 0.8G (10Hz-500Hz)
Sine Vibration
SlopeAcceleration Spectral
Density
Spectral Break Point
Frequencies
Random Vibration
(Operating)
6 db /octave-2.5 – 5 Hz
-0.1 [(m/s²)²]/Hz
(0.001 g²/Hz)
5 – 100 Hz
24 db /octave-100 – 200 Hz
Slope
Acceleration Spectral
Density
Spectral Break Point
Frequencies
Random Vibration
(Nonoperating and
Storage)
6 db /octave-2.5 – 5 Hz
-1.0 [(m/s²)²]/Hz*
(0.01 g²/Hz)
5 – 100 Hz
24 db /octave-100 – 200 Hz
11
Minimum ambient temperature for cold startup is 0ºC
12
Short-term exceptional conditions are for no longer than a one-year period of—96 consecutive hours,
or 360 hours total, or 15 occurrences.
Power Supply Specifications
2100-W AC-Input Power Supply Specifications
The following table lists specifications for the 2100 W AC input power supply:
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
148
Specifications
Power Supply Specifications

Cisco Catalyst 9400 Series Specifications

General

Series	Catalyst 9400 Series
Form Factor	Rack-mountable
Operating System	Cisco IOS XE
Uplink Options	40G and 100G uplinks
Stacking	Not supported
Layer Support	Layer 2 and Layer 3
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 90% noncondensing
Power Supply Options	AC and DC power supplies
Redundancy	Power supply, supervisor engine
Modular Slots	7 or 10
MAC Address Table Size	256, 000
Security Features	ACLs, TrustSec, MACsec
Management	CLI, SNMP, NETCONF, RESTCONF, Cisco DNA Center
