Cisco Catalyst 9400 Series User Manual

Installing a Fan Tray from the Front
To install a fan tray from the front, follow the steps described here.
Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Statement
1030
Warning
No user-serviceable parts inside. Do not open. Statement 1073
Warning
Installation of the equipment must comply with local and national electrical codes. Statement 1074
Warning
Before you begin
Ensure that a replacement fan tray (with the adapter module detatched), is ready for installation. There is a
time constraint when you remove and replace a fan tray in a system that is powered on - if you have enabled
the service mode prior to servicing, fan-less operation can be safely assured for four minutes only.
You may need a Phillips-head screwdriver to loosen the captive installation screws.
Procedure
Step 1 Grasp the front handle with one hand and place your other hand underneath the fan tray to support it. Hold
the fan tray with the fans facing to the right.
Step 2 Place the fan tray in the fan tray bay such that it rests on the chassis, and then lift the fan tray up slightly,
aligning the top and bottom guides.
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
90
Removing and Replacing FRUs
Installing a Fan Tray from the Front

Cisco Catalyst 9400 Series Specifications

General

Series	Catalyst 9400 Series
Form Factor	Rack-mountable
Operating System	Cisco IOS XE
Uplink Options	40G and 100G uplinks
Stacking	Not supported
Layer Support	Layer 2 and Layer 3
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 90% noncondensing
Power Supply Options	AC and DC power supplies
Redundancy	Power supply, supervisor engine
Modular Slots	7 or 10
MAC Address Table Size	256, 000
Security Features	ACLs, TrustSec, MACsec
Management	CLI, SNMP, NETCONF, RESTCONF, Cisco DNA Center
